OPERATOR'S STATION
1-81
Auto Air Conditioner
Components Name
1- Control Panel
2- Front Vent
3- Rear Vent
4- Foot Vent
5- Defroster Vent
6- OFF Switch
7- Blower Switch
8- Liquid-Crystal Display (LCD)
9- Temperature Control Switch
10- Mode Switch
11- AUTO Switch
12- Air Conditioner Switch
13- Circulation/Fresh Air Switch
14- Defroster Switch
NOTE: Except for the foot vent (4) and defroster vent (5),
all vents are provided with louvers to adjust the air flow
direction.
In addition, the louvers on the front vent and rear vent can be
completely opened and closed by hand.
MNDB-01-011
16 13
12 11 9 8 7 10 14
3
5
5
5
4
2
MNEC-01-035
MNDB-01-001
