OPERATOR'S STATION
1-65
Loading Control Lever Lock Switch
WARNING:
y Before leaving the operator's seat, be sure to stop
the engine. Place the boom and bucket in a level,
safe position. Then, set control lever lock switch (1)
to the LOCK (
) position.
y Always check to be sure that the control lever lock
switch (1) is set in the LOCK ( ) position before
transporting the machine or leaving the machine at
the end of the shift.
Refer to page 5-4 for details.
Control lever lock switch (1) is provided to prevent unexpected
machine operation, if the operator mistakenly comes in
contact with the bucket and/or lift arm control lever when
getting on or off the machine. When control lever lock switch
(1) is placed to UNLOCK (
) position, control lever lock
indicator (2) goes OFF and the loading control lever becomes
operable.
1
1
UNLOCK
LOCK
MNEC-01-015
70MNDB-01-04
2
MNDB-01-008
To Next Page
