OPERATOR'S STATION
1-67
Power Mode Selector
Two operation modes are available and can be selected by
power mode selector (1) depending on the applications.
Each time the switch is pressed, the power mode is
activated (ON) and deactivated (OFF) alternately.
Power
mode
(ON)
: The power mode is suitable for heavy digging
work prioritizing work effectiveness.
Under auto shifting mode, the gear is shifted
in regular engine RPM's (min
-1
) and shift
mapping.
Power
mode
(OFF)
: When the power mode is turned OFF, the
machine operates putting more emphasis on
lowering fuel consumption.
Under auto shifting mode, the gear is shifted
with lower engine RPM's (min
-1
) and shift
mapping.
When the power mode is activated, the symbol (
) (2) will
light on the monitor panel.
NOTE: When turning the start key switch ON, the power
mode is set to OFF.
MNEC-01-016
1
1
MNDB-01-008
2
70MNDB-01-04
To Next Page
