MOVING THE MACHINE
4-2
Starting to Move
WARNING: Start to move the machine only after
checking that no personnel and/or obstacles are
present around the machine.
Never turn ride control switch (4) (option) to ON
position when traveling the machine or raising the
bucket. Before turning the ride control switch (4) ON,
stop the machine and confirm that no one is around
the bucket. Avoid turning ride control switch (4) to ON
position while moving the machine. Failure to do so
may automatically move the lift arm up or down.
Refer to page 1-71 for detailed information of ride control
switch (4).
1. Check that none of the warning indicators except
parking brake indicator (1) on the monitor panel are ON
when engine is running.
2. Set the front attachment in the operating position by
operating control levers (2) (3).
3. Turn neutral lever lock (5) to the UNLOCK (
) position.
MNEC-04-001
A
Operating Position
A: 300 mm (1 ft)
MNEC-07-001
4
2
3
5
1
MNDB-01-008
MNDB-01-002
To Next Page
