OPERATOR'S STATION

1-108

Vandal-Resistant Devices

Locks can be installed to transmission inlet cap (1), tool box (2),

battery covers (3), and radiator inlet cover (4) (optional).

M4GB-01-147

MNDB-01-028

MNDB-01-014
