MAINTENANCE
7-107
No. Locations Bolt Diameter Quantity Wrench Size
Torque
N·m (kgf·m, lbf·ft)
16 Radiator frame mounting bolt * 16 6 24 154 (16, 115)
17 Radiator mounting bolt 8 2 12 17.6 (1.8, 13)
18 Intercooler mounting bolt 8 1 12 17.6 (1.8, 13)
19 Oil cooler mounting bolt 10 2 17 50 (5, 37)
20 Torque converter cooler mounting bolt 10 4 17 36.2 (4, 27)
21 Air conditioner condenser mounting bolt 8 4 12 12.5 (1, 9)
22 Air conditioner compressor mounting bolt
8412
24.5 to 29.4
(2.5 to 3, 18 to 22)
23 Cab cushion rubber mounting bolt * 16 (Nut) 4 24 205 (21, 151)
24 Bucket tooth mounting bolt (Optional) **11/4’ 16 46 1940 (198, 1430)
25 Cutting edge mounting bolt **1’ 12 37.47 1068 (109, 790)
26 Wear plate mounting bolt **1’ 4 37.47 1068 (109, 790)
* Apply "LOCTITE® 262" to the threads.
Figures with ** mark are shown in Inch.
