COMPONENTS NAME
1-2
Components Name
70TM7
1- Cutting Edge (BOC)
2- Bucket
3- Lever (Bell Crank)
4- Bucket Cylinder
5- Front Combination Light
(Headlight/Turn Signal/Clearance Light/Hazard Light)
6- Outside Rear View Mirror
7- Front Work Light
8- ROPS Cab
9- Rear Fender
10- Front Fender
11- Lift Arm Cylinder
12- Lift Arm
13- Exhaust Pipe
14- Hydraulic Oil Tank
15- Articulation Lock Bar
16- Rear Work Light
17- Battery (One each on both the right and left sides)
18- Rear Combination Light
(Turn Signal/Hazard Light/Tail Light/Brake Light/Backup
Light)
19- Counterweight
20- Towing Pin
21- Fuel Filler Port
22- Radiator/Oil Cooler
23- Link
24- Guide
25- Bucket Link
MNDB-01-064
1
2
4
3
5
6
7
8
9
10
11
12
MNDB-01-065
13
22
21
20
19
18
17
16 15 14
23 24
25
