4 Remote Interface Reference
224 Keysight 33210A User’s Guide
FREQuency:CENTer {<frequency>|MINimum|MAXimum}
FREQuency:CENTer? [MINimum|MAXimum]
Set the center frequency (used in conjunction with the frequency span).
Select
from 1 mHz to 10 MHz
(limited to 100 kHz for a ramp waveform). The default is
550 Hz. MIN = 1 mHz. MAX = based on the frequency span and maximum
frequency for the selected function
as shown below. The :CENT? query returns the
center frequency in hertz.
Center Frequency (max) = Max. Frequency –
– The following equation shows the relationship between the center frequency
and the start / stop frequency.
Center Frequency =
FREQuency:SPAN {<frequency>|MINimum|MAXimum}
FREQuency:SPAN? [MINimum|MAXimum]
Set the frequency span (used in conjunction with the center frequency).
Select
from 0
Hz to 10 MHz (limited to 100 kHz for a ramp waveform). The default is
900 Hz. MIN = 0 Hz. MAX = based on the center frequency and maximum
frequency for the selected function. The :SPAN? query returns the span in hertz
(can be a positive or negative value).
Frequency Span (max) = 2 × (Max. Frequency – Center Frequency)
– To sweep up in frequency, set a positive frequency span.
To sweep down in frequency, set a negative frequency span.
– The following equation shows the relationship between the span and the start /
stop frequency.
Frequency Span = Stop Frequency – Start Frequency
Span
2
----------
Stop Frequency Start Frequency –
2
--------------------------------------------------------------------------
