Front-Panel Menu Operation 2
Keysight 33210A User’s Guide 45
Configure system-related parameters.
– Generate a dc-only voltage level.
– Enable / disable the Sync signal which is output from the “Sync” connector.
– Select the output termination (1Ω to 10 kΩ, or Infinite).
– Enable / disable amplitude autoranging.
– Select the waveform polarity (normal or inverted).
– Select the GPIB address.
– Specify the LAN configuration (IP address and network configuration).
–
Select how periods and commas are used in numbers displayed on the front
panel.
– Select the local language for front-panel messages and help text.
– Enable / disable the tone heard when an error is generated.
– Enable / disable the display bulb-saver mode.
– Adjust the contrast setting of the front-panel display.
– Perform an instrument self-test.
– Secure/unsecure the instrument for calibration and perform manual
calibrations.
– Query the instrument’s firmware revision codes.
