Installation
06-237619-001 4-7 April 2020
4-5 CYLINDER BANK INSTALLATION
Before the cylinder installation begins, it is strongly recommended that door(s) to the cylinder
storage room are secured in the OPEN position. Use signs and warning tape to restrict access
to the area. No other tasks should be performed while installing the cylinders.
The cylinders and associated fixing equipment shall be placed and installed according to the
project specific cylinder bank assembly layout.
4-5.1 Typical Floor Load
Ensure the floor can support the total load of the cylinders. Use these table to calculate the
floor load of the cylinder bank.
Note: When cylinders banks are installed on top of subfloors, additional supports under the
subfloor may be required.
Table 4-5. Approximate Weight per Foot of 80.0 Liter Cylinders
Number of
Rows
IG-100 IG-55
Weight (lb) Weight (lb)
200 bar 300 bar 200 bar 300 bar
Single row 244 257 254 272
Double row 487 515 508 545
Triple row 731 772 762 817
