Kidde IG-100 User Manual

Installation
06-237619-001 4-9 April 2020
4-5.2.2 2 Row Wooden Racking Layouts
Figure 4-6. Dual Row Racking System with Clamps
Table 4-7. Dimensions for Racking Systems with Clamps
Cylinder
Size
Dimension in inches (mm)
Floor to
Clamping
Bar
Floor to
Bottom of
Manifold
Center Rear
Cylinder to
Manifold
Check Valve
Center Front
Cylinder to
Manifold
Check Valve
Cylinder
Centers
(Side to
Side)
Cylinder
Centers
(Front to
Back)
Centre of
Cylinders
(front and
rear) to
Manifold
Centre Offset
AB C D E F G
80 L 43.3
(1100)
78.7
(2000)
14.4 (365) 12.0 (305) 12.0 (305) 12.2 (310) 6.1 (155)
D
A
B
C
E
G
F
Note:
• Manifolds can be offset to the
left (as illustrated) or to the
right of the cylinders.
