Component Descrip
tions
April 2020
2-16
06-237619-001
2-4.9
Odorizer Assembly
The odorizer assembly, P/N 81-8976
00-000, inject
s a scent
of wintergreen into the agent
during a discharge. Upon disc
harge, the agent
pressure ruptures a burs
t disc to release
the
scent of wintergreen. This scent warns personnel
i
n the vicinity of the area protected by the
fire suppression system
that ag
ent is present.
Figure 2-20.
Odorizer Assembly
8.7” REF
2.0” REF
3/4” NPT
CONNECTION
55
57
