Component Descrip
tions
April 2020
2-28
06-237619-001
2-8.3.2.3
Plain-nut Discharge Head
The plain-nut discharge head (P/N WK-872450-000)
discharges the contents of the 1040 cu.
in. Nitroge
n pilot cylind
er upon activ
a
tion of its associated control head.
Figure 2-35. Discharge Head, Plain Nut
3-15/16
in.
(100
mm)
STOP
CHECK
SET
POSITION
OPERA
TED
POSITION
SWIVEL
NUT
(FOR
CONNECTION
TO
CYLINDER
V
AL
VE)
STEM
INNER
O-RING
P/N
WF-242467-000
OUTER
O-RING
P/N
WF-242466-000
2-1/2
-
14N3
3/4
in.
NPS
DISCHARGE
OUTLET
SPRING
BALL
CHECK
BALL
RET
AINER
PISTON
3-13/16
in.
(97
mm)
67
69
