Parts List
April 2020 8-14 06-237619-001
8-11 FILL ADAPTERS
8-12 MANIFOLD EQUIPMENT
Table 8-15. Kidde IGS Fill Adapter Part Numbers
Description Part Number
European Filling Adapter Assembly
38-406000-001
O-Ring for Filling Adapter 38-406000-003
Nitrogen Cylinder Recharge Adapter WK-933537-000
O-Ring for Nitrogen Cylinder Recharge Adapter (P/N WK-933537-000) WK-197008-000
Table 8-16. Kidde IGS Manifold Equipment Part Numbers
Description Part Number
80 Liter 2 Stub 1 Row 2" Manifold BSP, with 2 manifold check valves 38-351000-004
80 Liter 3 Stub 1 Row 2" Manifold BSP, with 3 manifold check valves 38-351000-005
80 Liter 4 Stub1 Row 2" Manifold BSP, with 4 manifold check valves 38-351000-006
80 Liter 5 Stub 1 Row 2" Manifold BSP, with 5 manifold check valves 38-351000-007
80 Liter 6 Stub 1 Row 2" Manifold BSP, with 6 manifold check valves 38-351000-008
80 Liter 4 Stub 2 Row 2" Manifold BSP, with 4 manifold check valves 38-351000-009
80 Liter 6 Stub 2 Row 2" Manifold BSP, with 6 manifold check valves 38-351000-010
80 Liter 8 Stub 2 Row 2" Manifold BSP, with 8 manifold check valves 38-351000-011
2" BSP Manifold Coupling 38-400020-100
2" BSP Manifold End Cap 38-400020-101
3/4" BSP Manifold End Cap For 14mm Check Valve 38-400020-102
2" Adapter, BSPT (F) to NPT (F) 38-351000-001
Bracket for 80L Cylinder manifold 1 Row 200mm (inc 2" Clamp) 01-8160-0200
Bracket for 80L Cylinder Manifold 2 Rows 520 mm (inc 2" Clamp) 01-8160-0520
Bracket for 80L Cylinder Manifold 3 Rows 830 mm (inc 2" Clamp) 01-8160-0830
2" Pipe Clamp ø58.7 - ø63.5 mm 01-8143-0000
