Parts List
06-237619-001 8-13 April 2020
8-10 DISCHARGE DELAY, SIREN, AND ASSOCIATED ACCESSORIES
Table 8-14. Kidde IGS Discharge Delay, Siren, and Associated Accessories Part Numbers
Description Part Number
Nitrogen Pilot Cylinder, 108 cu. in. (1.77 L) with Supervisory Pressure Switch, Normally
Open Under Pressure
06-129773-001
1040 cu. in. Nitrogen Pilot Cylinder w/pressure switch 90-101040-200
30 Second Nitrogen Discharge Delay Kit which includes:
• Nitrogen Discharge Delay for use with 108 cu. in. Pilot Cylinder
(P/N 81-871072-001)
• 3/4” Male x 1/4” NPT Female Bushing Adapter
• 1/4” BSPP Male x NPT Male Straight Adapter
• 1/4” BSPP Female x NPT Male Straight Adapter
• 1/3” NPT Female 90° Elbow Connector
• 1/4” NPT Male x 6mm Tube OD Adapter
• Back-Plate Manifold Hose (P/N 01-3273-1200)
38-401140-030
60 Second Nitrogen Discharge Delay Kit which includes:
• Nitrogen Discharge Delay for use with 108 cu. in. Pilot Cylinder
(P/N 81-871072-002)
• 3/4” Male x 1/4” NPT Female Bushing Adapter
• 1/4” BSPP Male x NPT Male Straight Adapter
• 1/4” BSPP Female x NPT Male Straight Adapter
• 1/3” NPT Female 90° Elbow Connector
• 1/4” NPT Male x 6mm Tube OD Adapter
• Back-Plate Manifold Hose (P/N 01-3273-1200)
38-401140-060
Siren, Nitrogen Pressure Operated 90-981574-001
Male Connector, 5/16” Flare x 1/8” NPT WK-699205-010
Mounting Bracket, Nitrogen Pilot Cylinder 108 cu. in. WK-877845-000
Actuation Hose, 30” WK-264986-000
Cylinder Strap, Nitrogen Pilot Cylinder 1040 cu. in. WK-270014-000
Discharge Head, Plain Nut WK-872450-000
Flexible Hose, 3/4” Outlet WK-251821-000
Electric Control Head, 24 VDC Kit with Control Head Monitor 85-890181-000
Lever Operated Control Head WK-870652-000
Lever/Pressure Operated Control Head 82-878751-000
Control Head Monitor, with Hazloc Assembly (as spare) 85-100000-100
