Kidde IG-100 User Manual

Parts List
06-237619-001 8-5 April 2020
8-7 SELECTOR VALVES
8-8 LOCKOUT VALVES
Table 8-7. Kidde Fire Protection IGS Selector Valve Part Numbers
Description Part Number
1” Selector valve, DN 25, 8-10 Bar Actuator 22-37140-025
1 1/2” Selector valve, DN 40, 8-10 Bar Actuator 22-37140-040
2” Selector valve, DN 50, 8-10 Bar Actuator 22-37140-050
3” Selector valve, Flange DN 80, 8-10 Bar Actuator 22-37140-080
4” Selector valve, Flange DN 100, 8-10 Bar Actuator 22-37140-100
Back-Plate Manifold - 2 Area, Selector Valve Control, 8 Bar 01-3508-0002
Back-Plate Manifold - 3 Area, Selector Valve Control, 8 Bar 01-3508-0003
Back-Plate Manifold - 4 Area, Selector Valve Control, 8 Bar 01-3508-0004
Back-Plate Manifold - 5 Area, Selector Valve Control, 8 Bar 01-3508-0005
Back-Plate Manifold Hose 01-3273-1200
1" BSPT (M) to NPT (F) Adapter 01-3711-3000
1 1/2" BSPT (M) to NPT (F) Adapter 01-3711-4000
2" BSPT (M) to NPT (F) Adapter 01-3711-5000
Nipple 1/4" BSPP 60° - 1/4" BSPT M/M 15-8662-0042
Nipple 1/4" BSPP 60° x 1/8" BSPT M/M 15-8662-0041
Pressure Regulator - 300 Bar to 8 Bar 01-6017-0000
Back-Plate Manifold Spare Solenoid 38-350800-001
Table 8-8. Kidde IGS Lockout Valve Part Numbers
Description Part Number
Valve, 1" NPT Lockout (Isolation) 38-409830-005
Valve, 2" NPT Lockout (Isolation) 38-409830-007
Valve, 3" NPT Lockout (Isolation) 38-409830-009
Valve, 4" NPT Lockout (Isolation) 38-409830-010
