Parts List
06-237619-001 8-7 April 2020
8-9.1 Listed 360 Degree Nozzles
Kidde offers the 360 degree nozzle in brass for both NPT and BSP piping.
Table 8-10. Kidde IGS Listed 360 Degree NPT Nozzles
Orifice
Diameter
(mm)
Area Orifice Area
mm
2
in.
2
0.5” 0.75” 1.00” 1.50”
3 7.0686 0.0110 38-407100-030
3.5 9.6211 0.0149 38-407100-035
4 12.5664 0.0195 38-407100-040
4.5 15.9043 0.0247 38-407100-045
5 19.6350 0.0304 38-407100-050
5.5 23.7583 0.0368 38-407100-055
6 28.2743 0.0438 38-407100-060
6.5 33.1831 0.0514 38-407100-065
7 38.4845 0.0597 38-407100-070 38-407200-070
7.5 44.1786 0.0685 38-407100-075 38-407200-075
8 50.2655 0.0779 38-407100-080 38-407200-080
8.5 56.7450 0.0880 38-407100-085 38-407200-085
9 63.6173 0.0986 38-407100-090 38-407200-090
9.5 70.8822 0.1099 38-407100-095 38-407200-095
10 78.5398 0.1217 38-407100-100 38-407200-100 38-407300-100
10.5 86.5901 0.1342 38-407200-105 38-407300-105
11 95.0332 0.1473 38-407200-110 38-407300-110
11.5 103.8689 0.1610 38-407200-115 38-407300-115
12 113.0973 0.1753 38-407200-120 38-407300-120
12.5 122.7185 0.1902 38-407200-125 38-407300-125
13 132.7323 0.2057 38-407200-130 38-407300-130
13.5 143.1388 0.2219 38-407200-135 38-407300-135
14 153.9380 0.2386 38-407200-140 38-407300-140 38-407400-140
14.5 165.1300 0.2560 38-407300-145 38-407400-145
15 176.7146 0.2739 38-407300-150 38-407400-150
15.5 188.6919 0.2925 38-407300-155 38-407400-155
16 201.0619 0.3116 38-407300-160 38-407400-160
16.5 213.8246 0.3314 38-407300-165 38-407400-165
17 226.9801 0.3518 38-407300-170 38-407400-170
17.5 240.5282 0.3728 38-407300-175 38-407400-175
18 254.4690 0.3944 38-407300-180 38-407400-180
18.5 268.8025 0.4166 38-407400-185
19 283.5287 0.4395 38-407400-190
19.5 298.6477 0.4629 38-407400-195
20 314.1593 0.4869 38-407400-200
