Component Descriptions
06-237619-001 2-3 April 2020
The Kidde IGS equipment listed herein is designed for an operating temperature range of -4°
to 130°F (-20° to 54°C). The Agent information found in Section 1-5 shows the cylinder
temperature-pressure relationship formulas based on fill density.
The Kidde Fire Suppression System Flow Calculation Program is designed for a 68°F (20°C)
cylinder operating/storage temperature.
Figure 2-3. Kidde Inert Agent and Cylinder Part Number Breakdown
2-3.1.1 Spare Parts for Cylinders
The following spare parts are available for the cylinder:
Table 2-1. Dimensions. Cylinder and Valve Assemblies
Part Number Capacity
Approximate Empty
Weight
Height Diameter
Volume
BA
lb kg in mm in mm
in
3
m
3
38-4X80X1-XXX 80 L 227.1 103.0 73.3 1862 10.5 267 4882 0.08
Note: Agent choice does not alter cylinder dimensions, only filled weights. For weights, see Table 2-2.
Table 2-2. Filled Cylinder Weights
Part Number Capacity Pressure
IG-100 IG-55
lb kg lb kg
38-4X8021-XXX 80 L 200 bar 266.4 120.8 277.4 125.8
38-4X8023-XXX 80 L 300 bar 281.4 127.6 297.9 135.1
Table 2-3. Kidde IGS Cylinder Spare Parts
Part Number Description
38-400011-001 Muller anti-recoil cap, with actuation test pin
15-9604-0011 Transport Cap for 80L cylinders
38 – 4 X 80X 1 X X X –
Agents
055 = IG55 (Argonite)
100 = IG100 (Nitrogen)
Fill Pressure
2 = 200 bar
3 = 300 bar
Brand
1 = Kidde Fire Protection
2 = Kidde Fire Systems
Description
