Kidde IG-100 User Manual

Parts List
06-237619-001 8-11 April 2020
20.5 330.0636 0.5116 38-407800-205
21 346.3606 0.5369 38-407800-210
21.5 363.0503 0.5627 38-407800-215
22 380.1327 0.5892 38-407800-220
22.5 397.6078 0.6163 38-407800-225
23 415.4756 0.6440 38-407800-230
23.5 433.7361 0.6723 38-407800-235
24 452.3893 0.7012 38-407800-240
24.5 471.4352 0.7307 38-407800-245
25 490.8739 0.7609 38-407800-250
25.5 510.7052 0.7916 38-407800-255
26 530.9292 0.8229 38-407800-260
Table 8-13. Kidde IGS Listed 180 BSP Degree Nozzles
Orifice
Diameter
(mm)
Area Orifice Area
mm
2
in.
2
0.5” 0.75” 1.00” 1.50”
3 7.0686 0.0110 38-417500-030
3.5 9.6211 0.0149 38-417500-035
4 12.5664 0.0195 38-417500-040
4.5 15.9043 0.0247 38-417500-045
5 19.6350 0.0304 38-417500-050
5.5 23.7583 0.0368 38-417500-055
6 28.2743 0.0438 38-417500-060
6.5 33.1831 0.0514 38-417500-065
7 38.4845 0.0597 38-417500-070 38-417600-070
7.5 44.1786 0.0685 38-417500-075 38-417600-075
8 50.2655 0.0779 38-417500-080 38-417600-080
8.5 56.7450 0.0880 38-417500-085 38-417600-085
9 63.6173 0.0986 38-417500-090 38-417600-090
9.5 70.8822 0.1099 38-417500-095 38-417600-095
10 78.5398 0.1217 38-417500-100 38-417600-100 38-417700-100
10.5 86.5901 0.1342 38-417600-105 38-417700-105
11 95.0332 0.1473 38-417600-110 38-417700-110
11.5 103.8689 0.1610 38-417600-115 38-417700-115
12 113.0973 0.1753 38-417600-120 38-417700-120
12.5 122.7185 0.1902 38-417600-125 38-417700-125
Table 8-12. Kidde IGS Listed 180 NPT Degree Nozzles (Continued)
Orifice
Diameter
(mm)
Area Orifice Area
mm
2
in.
2
0.5” 0.75” 1.00” 1.50”
