PWR-01 11
No.
Name Function
1 DC OUTPUT terminal Rear-panel output terminal. p.24
2
Chassis terminal A connector for grounding the output. p.24
3 LAN port
1
Ethernet port for controlling the PWR-01 remotely.
Communication
Interface Manual
4
RS232C/ TRG IN
connector
1
RS232C port for controlling the PWR-01 remotely.
Trigger signal input connector. The common terminal is connected to the
chassis.
5 TRG OUT connector
1
Trigger signal output terminal. The common terminal is connected to the
chassis.
6 USB port
1
1. A connector cover or terminal cover is attached when the product is shipped from the factory.
USB port for controlling the PWR-01 remotely.
7
Sensing terminal Terminals to connect the sensing cables to. p.30
8
Air outlet Air outlet for internal cooling. –
9AC INPUT
400W model/ 800W model: AC inlet.
1200W model: AC INPUT terminal block.
p.14
p.15
10 J1 connector
1
For external control and master-slave parallel operation. p.85, p.104
11 J2 connector
1
External control p.85
