138 PWR-01
B
Options
The PWR-01 has the following options.
For information about options, contact your Kikusui agent or distributor.
Rack mount option
Remove the handle and rubber feet before you mount the PWR-01 to a rack.
For information on rack mounting, see the KRA3 or KRA150 operation manual.
To support the main unit, attach an angle support to it that is appropriate for the rack.
We recommend that you keep all pieces that you remove from the PWR-01. You will need
these pieces if you remove the PWR-01 from the rack mount adapter.
When you re-attach the original rubber feet, use the pieces that you removed.
Name Model Note Applicable model
Rack mount adapter KRA3 For EIA inch racks 400W model
800W model
1200W model
KRA150 For JIS millimeter racks
KRA150
( 460)
480
( 460)
482
149
24.5
100
57
260
260
37.75
KRA3
Unit: mm (inches)
To reinstall the handle that has been removed, use screw locking agent (e.g., 1401B by
ThreeBond International, Inc.) to prevent screws from loosening.
