PWR-01 55
Basic Features ｜ CONFIG Settings
LAN
3
CF50 IP1 Ip addr. 1 IP address display (1)
——
CF51 IP2 Ip addr. 2 IP address display (2)
——
CF52 IP3 Ip addr. 3 IP address display (3)
——
CF53 IP4 Ip addr. 4 IP address display (4)
——
CF54 HA1 HW. addr. 1, 2 MAC address display (1) and (2)
——
CF55 HA2 HW. addr. 3, 4 MAC address display (3) and (4)
——
CF56 HA3 HW. addr. 5, 6 MAC address display (5) and (6)
——
CF60 BOOT LAN Reboot LAN setting reset (LCI/ DEF)/ apply (APPL)
—
○
CF61 ADR Address config IP address assignment method
■
△ / ◇
CF62 S.IP1 Static IP 1 Manual IP address setting (1)
■
△ / ◇
CF63 S.IP2 Static IP 2 Manual IP address setting (2)
■
△ / ◇
CF64 S.IP3 Static IP 3 Manual IP address setting (3)
■
△ / ◇
CF65 S.IP4 Static IP 4 Manual IP address setting (4)
■
△ / ◇
CF66 SUB Subnet Mask IP address subnet mask
■
△ / ◇
CF67 DOM VMCB Dom. Multichannel (VMCB) domain number
■
2
△
CF68 CH VMCB Ch. Multichannel (VMCB) channel number
■
2
△
USB CF70 VID V. ID Vendor ID (VID) display
——
CF71 PID P. ID Product ID (PID) display
——
RS232C CF72 BAUD Baud rate RS232C baud rate
—
△
Sequence CF80 PROG Program Program’s user code display (execute)
——
CF81 REM.L Rem. Loop Remaining program repetition count display
——
CF82 REM.T Rem. Time Remaining program time display
——
CF83 TRG.I Trig. In Trigger input signal polarity
—
○
CF84 TRG.O Trig. Out Trigger output signal polarity
—
○
1 You can also specify this parameter when the PWR-01 is being used as a slave unit.
2 This parameter is affected only when the LAN interface settings are reset (CF60: DEF).
3 For details on the LAN interface settings, see the “Communication Interface Manual” on the included CD-ROM.
Display
switching
Parameter
number
Mnemonic Setting/ display Effect Note
