PWR-01 61
Basic Features ｜ CONFIG Settings
CF15 (E.LOG) External control logic for turning output on/ off
Sets the logic that is used for output on/ off control using an external contact (p.94).
CF16 (STS.C) CC status signal polarity
Sets the polarity of the status signal for monitoring the constant-current mode (p.98).
CF17 (STS.V) CV status signal polarity
Sets the polarity of the status signal for monitoring the constant-voltage mode (p.98).
CF18 (STS.O) Output status signal polarity
Sets the polarity of the status signal for monitoring the output-on state (p.98).
CF19 (STS.A) Protection function/ alarm status signal polarity
Sets the polarity of the status signal for monitoring the protection function or alarm (p.98).
CF20 (A.RCV) Output when AC-FAIL protection is released
Sets the output state when a low AC input protection (AC-FAIL) is released (p.46).
This parameter is applied when you turn the POWER switch off and on.
You can also set this parameter when the PWR-01 is being used as a slave unit.
Display Description
LO LOW The output is turned on with a low signal (0 V to 0.5 V) or short cir-
cuit (factory default setting).
HI HIGH The output is turned on with a high signal (4.5 V to 5 V) or open cir-
cuit.
Display Description
NEG Negative Negative (factory default setting)
POS Positive Positive
Display Description
NEG Negative Negative (factory default setting)
POS Positive Positive
Display Description
NEG Negative Negative (factory default setting)
POS Positive Positive
Display Description
NEG Negative Negative (factory default setting)
POS Positive Positive
Display Description
SAFE Safe After the problem that caused an alarm to occur is fixed, the output
is not turned on automatically (factory default setting).
AUTO Auto After the problem that caused an alarm to occur is fixed, the output
is turned on automatically.
