PWR-01 63
Basic Features ｜ CONFIG Settings
CF32 (SC3) CONFIG parameter shortcut registration (SC3)
Registers a CONFIG setting parameter to the front panel’s SC3 key (p.72).
CF33 (BEEP) Buzzer on/ off
Turns the buzzer on and off.
The buzzer sounds when settings are reset to factory defaults, when a communication com-
mand error occurs, or when a preset memory or sequence program cannot be recalled.
CF34 (BRI) Panel display brightness
Sets the panel display brightness. The larger the number, the brighter the display.
Even if you specify the same number, the brightness may be different between individual
products.
The brightness is not proportional to the setting.
You can also set this parameter when the PWR-01 is being used as a slave unit.
CF35 (AMTR) Slave unit display during master-slave parallel oper-
ation
Sets whether the current or power on slave units is displayed during master-slave parallel
operation. If the slave unit display is disabled, the ammeter shows "
----.”
CF40 (LAN) LAN interface setting
Enables or disables the LAN interface.
By setting this parameter to “OFF,” you can disable the LAN interface function even when a
LAN cable is connected.
This parameter is applied when you turn the POWER switch off and on.
Display Description
00 00 CONFIG parameter not registered (factory default setting)
01 to 99 01 to 99 CF01 to CF99
Display Description
OFF OFF Buzzer off
ON ON Buzzer on (factory default setting).
Display Description
1 to 7 1 to 7 Screen brightness adjustment (factory default setting: 7)
Display Description
OFF OFF Slave unit display disabled (factory default setting)
ON ON Slave unit enabled
Display Description
OFF OFF LAN disabled
ON ON LAN enabled (factory default setting).
To Next Page
