Kohler KDI 1903M Workshop Manual

5
INFORMATION REGARDING DISCHARGE OF
LIQUIDS
EN 58
5 INFORMATION REGARDING DISCHARGE OF
LIQUIDS
5.1 Coolant
Important
•
Before proceeding with operation, read Par. 3.3.2.
NOTE:
Component not necessarily supplied by
KOHLER
.
The representation of the radiator is purely indicative.
Warning
• Presence of steam pressurized coolant danger of burns.
1.
Undo the cap A carefully (circuit under pressure).
Fig 5.1
2.
Loosen cap D, remove gasket E, drain all coolant i
n
ra
diator G into a suitable container and refer to Par.
3.6.
Fig 5.2
3.
Undo cap F to drain all liquid from the system
contained in the engine crankcase ducts into an
appropriate container (Par. 3.6).
Fig 5.3
