Kohler KDI 1903M - 3 Rd PTO (Replacement)

11
INFORMATION ABOUT OPTIONAL
COMPONENTS
EN 152
3.
Position the gear unit
B
on the hole
J
using the
bushing G to centre.
4.
Secure the gear B using the screw A inserting the
washer H (tightening torque at see service letter
700019 - 700021).
11.6 3rd PTO (replacement)
F
ig 11.12
Important
•
Before proceeding with operation, read Par.
3.3.2.
11.6.1 Disassembly
1.
Undo the screws A and remove the pump B.
Fig 11.13
