Kohler KDI 1903M Workshop Manual

6
INFORMATION FOR REPLACING THE
FUNCTIONAL UNITS
EN 68
6.1.10 Installation of the fuel injector pipes
(pump injector/injectors)
1.
Position pipes D on the injectors and on the
injector pump.
I
mportant
•
Tighten the nuts E and F manually, witho
ut
c
lamping them.
2. Tighten the nuts
E
ed
F
(tightening torque a
t
25 N
m
).
3. Reinstall the retainers
C
of the hoses
D
.
4. Fix the plate
B
by using screws
A
(tightening torque to
10 Nm
).
F
ig 6.29
Fig 6.30
6.2 Coolant pump replacement
6.2.1 Disassembly
1.
Perform the operations described in Par. 5.1.
I
mportant
•
Before proceeding with operation, read Par. 3.3.2.
•
The pump G isn't repairable.
2. Lo
osen the screws A and B.
3. Push the alternator C in the direction of the arrow D
and remove the belt E.
4. Loosen the screws F and remove the pump G an
d
r
elative gasket H.
Fig 6.31
Fig 6.32
