Kohler KDI 1903M Workshop Manual

11
INFORMATION ABOUT OPTIONAL
COMPONENTS
EN 164
5.
Clamp the fitting
K
(tightening torque at
45 Nm +
Loctite 2701).
6.
Clamp the fitting H on the flange J inserting the
gasket U (tightening torque at 65 Nm).
7.
Connect the hose B to the central fitting of support
M an
d of flange J.
8.
Connect the hose C to the side fitting of the
support M and of head J.
9.
Clamp the nuts A on the head J (tightening torque
at 48 Nm).
10.
Clamp the nuts A on the support M (tightening
torque at 48 Nm).
I
mportant
•
Check the tightening of the fittings H (Fig. 11.51)
and L (Fig. 11.52) (tightening torque at 65 Nm).
Fig 11.52
11.12 Intake circuit (replacement)
Important
•
Before proceeding with operation, read Par.
3.3.2.
11.12.1 Air filter disassembly
1.
Release the clamp B.
2.
Untighten the screws A and remove the filter C.
Fig. 11.53
