Kohler KDI 1903M Workshop Manual

GENERAL INFORMATION
1
9
EN
1.2 Manufacturer and engine identification
The engine identification name plate is situated in the lower part of the crankcase; it is visible from the
intake or exhaust side.
Fig 1.1 - Fig 1.2
F
ig 1.3

Kohler KDI 1903M Specifications

General

Engine Model	KDI 1903M
Engine Type	Diesel, 4-stroke
Number of Cylinders	3
Compression Ratio	17.5:1
Aspiration	Turbocharged
Dry Weight	190 kg
Bore x Stroke	88 mm x 102 mm
Max Torque	190 Nm (140 lb-ft) @ 1500 rpm
Fuel System	Direct Injection
Emissions Compliance	EU Stage V / EPA Tier 4 Final
Displacement	1.861 L (113.6 cu. in.)
Max Power Output	42 kW (56.3 hp) @ 2600 rpm
