BRAKE LEVER REPLACEMENT
1. Loose the secure nut (1) for the brake lever and unscrew the
brake lever bolt (2) with a at-headed screwdriver.
2. Now it is possible to remove the brake lever from the front
brake system.
3. Unscrew the adjustment screw (3). Screw the adjustment
screw in the new brake lever in.
4. Assemble the new brake lever in reverse order.
EXHAUST REPLACEMENT
In case of a damaged mufer remove the exhaust pear (1)
consisting of two parts or the silencer (2) and replace the damage
exhaust part with a new one.
If you remove the mufer short after a ride take care as the
mufer could be still very hot.
Exhaust pear
1. Remove the two springs (3) and disconnect the hose (4) of
the secondary air system.
2. Loosen the screw (5) and the two screws (6).
NOTE
STEERING/ EXHAUST
110
2
1
3
1
2
3
4
5
6
