KSR Moto TRIGGER 50 - Chassis; Left; Right Side Cover Removal

CHASSIS
143
COVER REPLACEMENT
SEAT REMOVAL
1. Turn the key clockwise (arrow) and lift the seat up.
2. To get off the seat, lift (1) the seat and pull it back (2).
3. Install the seat in reverse order
LEFT/RIGHT SIDE COVER REMOVAL
1. Remove the seat.
2. Remove the screws (1).
3. Remove the left/right side cover (2).
4. Install the left/right side cover in reverse order.
NOTE
Only one side (left side) is illustrated.
LEFT/RIGHT LOWER SIDE COVER REMOVAL
1. Remove the screws (1).
2. Remove the lower side cover (2).
3. Install the left/right lower side cover in reverse order.
NOTE
Only one side (left side) is illustrated.
1
2
1
2
1
2
