HEADLIGHT AIMING INSPECTION
1. Place the vehicle at a distance of 5 meters in front of a wall.
The vehicle must be placed horizontally.
2. Measure the distance from the ground to the middle of the
headlight bulb (X).
3. Transfer this value to the wall and mark it with an X.
4. Then make a second X, 5 centimetre below the rst X.
5. Turn the screw (1), placed on the front side of the headlight,
in or out to adjust the height of the low beam.
5 m
5 cm
X
X
1
ELECTRICAL SYSTEM
45
