KSR Moto TRIGGER 50 - Removal of Power Limitation Removal of Power Limitation

REMOVAL OF POWER LIMITATION
151
REMOVAL OF POWER LIMITATION
!
WARNING
THE REMOVAL OF POWER LIMITATION IS IN THE MOST
COUNTRIES NOT LEGAL. IN CAUSE OF DETHROTTLING
ALL CLAIMS OF WARRANTY EXPIRE AND ALL DAMAGES
OF THE VEHICLE IS IN YOUR OWN RESPONSIBILITY.
There are 2 levels of dethrottling.
Level 1 ( about 50-60 Km/h)
1. Remove the exhaust pear.
2. Cut off the throttle at the rst weld as shown in the picture (1).
3. Install the exhaust pear in reverse order.
Level 2 ( about 65-70 Km/h)
1. Remove the exhaust pear.
2. Cut off the complete throttle as shown in the picture (2).
3. Install the exhaust pear in reverse order.
4. Remove the carburettor.
5. Remove the carburettor cover (1).
6. Replace the main jet 95 (2) with a main jet 102.
7. Install the carburetto in reverse order.
8. Remove the spark plug.
9. Replace the spark plug NGK/BR8ES with a spark plug
NGK/BR7ES.
10. Install the spark plug in reverse order.
1
2
1
2
