KSR Moto TRIGGER 50 - Cover Front Shock Absorber Left Removal

CHASSIS
147
COVER FRONT SHOCK ABSORBER LEFT REMOVAL
1. Remove the screw (1).
NOTE
Look to the nut on the rear.
2. Thread of the breaking hose (2).
3. To remove the cover front shock absorber left (3) remove the
two screws (4).
4. To remove the side reector (5), press together the clip and
pull the side reector sidewards.
5. Install the cover front shock absorber left in reverse order.
1
2
4
3
5
