FUEL SYSTEM/ FUEL SUPPLY
56
FUEL COCK REMOVAL
NOTE
It´s recommended to drain the fuel from the tank before removal.
1. Switch off the ignition.
2. Switch the fuel cock to the “OFF” position.
3. Disconnect the fuel line from the Carburettor
4. Leave out the fuel (switch the fuel cock to the “ON” position).
5. Remove the fuel tank.
6. Lossen the two screws (1).
7. Remove the fuel cock.
8. Assembling in reverse order.
NOTE
Keep the fuel cock switch in correct position when tighten the
nut.
TORQUE LIST
For screws that are not listed use standard values (page 11).
PART. NO. TORQUE
1 Tighten that no fuel is leaking
1
