NOTE
• In Case of a defect of a transmission gear replace always in
a pair.
• Remove damaged bearings if necessary with a bearing pull-
er.
• Use only genuine spare parts.
• Before assembling the engine clean the crankcase and all
sealing surfaces carefully.
• Wash all used parts before install again and apply clean en-
gine oil to all moving and sliding parts.
• Replace all gaskets and check the condition and function of
each part during assembly carefully.
INSPECTION OF TRANSMISSION AND GEAR SHIFT
MECHANISM
NOTE
Check respectively wear of tooth surface (1) and drive pawls (2).
If they are seriously worn or damaged, replace them. Remove
bearing and oil seal on left crankcase. Check if bearing and oil
seal are injured. Replace if necessary.
ENGINE/ TRANSMISSION
70
