Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-3-92
U699 Set Soft SW
Description
Sets the software switches on the FAX control board individually.
Purpose
To change the setting when a problem such as split output of received originals occurs.
Since the communication performance is largely affected, normally this setting need not be
changed.
Method
1. Press the start key.
2. Press [SW No.].
3. Enter the desired software switch number (3 digits) using the numeric keys and press the
enter key.
Display Description
SW No. SW No.
4. Use numeric keys 7 to 0 to switch each bit between 0 and 1.
Display Description
Bit Set the soft switch.
5. Press the start key to set the value.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
List of Software Switches of Which the Setting Can Be Changed
<Communication control procedure>
No. bit Description
36 7654 Coding format in transmission
3210 Coding format in reception
37 5 33600bps/V34
4 31200bps/V34
3 28800bps/V34
2 26400bps/V34
1 24000bps/V34
0 21600bps/V34
38 7 19200bps/V34
6 16800bps/V34
5 14400bps/V34
4 12000bps/V34
3 9600bps/V34
2 7200bps/V34
1 4800bps/V34
