Kyocera ECOSYS M3540dn Service Manual

Revision history
Revision Date Pages Revised contents
1 14 February 2014 1-1-2 Correction: Power source → Rated input
1-1-3, 1-1-4 Correction: sheets/min → ppm, images/min → ipm
1-1-5 Correction: 18.Left cover → controller cover
1-1-12 Correction: (2)ECOSYS ... → 50/60 ppm model ...
1-2-1 Correction: 120V60Hz 10.0A →12.0A
1-2-3 Correction: The parts of No.15 and No.16
1-2-4 Added: Cautions sentence for carrying the machine
1-2-8 Correction: Left cover → controller cover
1-2-11 Changed: Procedures and Figure for the loading paper
1-2-15 Added: Setting the country code
1-3-16 Added: into the description of (60) Media type attributes
1-3-16, 17 Added: Contents addition in (62),(75), (78) to (81),
(84) to (87)
1-3-32 Changed: Figure 1-3-9 in U070
1-3-38 Changed: Procedure in U201
1-3-40 Changed: Procedure in U207
1-3-44 Added: Error codes
1-3-54, 1-3-55
1-3-58 to 60
Changed: Item number of original
1-3-55 to 57 Correction: List of the Error Codes
1-3-62 Added: a display of TDRS connection state
1-3-63, 1-3-65 Correction: The position of "Excute"
Correction: Kind of error
1-3-98 Correction: Procedure in U917
1-3-106,
1-3-109,
1-3-110
Added: Completion
1-3-107 Added: 254 Taiwan to Destination code list
1-4-83 Correction: right cover → rear cover
1-4-108 Added: Error code 3102
1-5-11 Added: Procedure 8 “Remove...”
1-5-16 Deleted: Procedure 5 “Refit...”
1-5-20, 1-5-52 Added: Procedure 4 “Open the ...”
1-5-20, 1-5-21,
1-5-52, 1-5-53,
1-5-59, 1-5-64,
1-5-65, 1-5-67,
1-5-86, 1-5-87,
1-5-94, 1-5-95
Correction: Names of cover
(upper right cover → right upper cover)
(right upper cover → right middle cover)
(upper left cover → left upper cover)
(left upper cover → left middle cover)
(right upper cover → front right cover)
1-5-71 Correction: Duplex assembly → Duplex conveying unit
1-5-82 Deleted: Procedure 3

Kyocera ECOSYS M3540dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Type	Color CIS
Scan Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Paper Capacity	500 sheets
Connectivity	USB, Ethernet
Copying	Yes
Scanning	Yes
Modem Speed	33.6 kbps
Standard Input Capacity	500 sheets
Standard Output Capacity	250 sheets
Maximum Output Capacity	250 sheets
Maximum Print Size	A4
Standard Interfaces	USB 2.0, Ethernet
Ethernet LAN	Yes
Internal Memory	512 MB
Power Consumption (typical)	661 W
Display	LCD
Functions	Print, Copy, Scan, Fax
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm (pages per minute)
Copy Speed	40 cpm (copies per minute)
Standard Paper Tray Media Types	Recycled
Maximum Internal Memory	1, 536 MB
Weight	22 kg
Product Colour	Black
