2NM/2NX/2NY/2NZ/2P0/2P6
2-3-13
(5) Chart of image adjustment procedures
Adjust-
ing order
Item Image
Maintenance mode
Page
Setting procedure
Remarks
Item No. Mode
Method Setting
1 Adjusting the center line of the MP
tray
(printing adjustment)
Adjusting the LSU print start timing
U034 LSU Out Left P.1-3-24 1. Press the start key.
2. Select [Lsu Out Left] to be adjusted.
3. Press the start key.
4. Press the system menu key.
5. Press the start key.
(output a test pattern)
6. Press the system menu key.
7. Select [MPT] to be adjusted.
1. Change the setting value using
the cursor +/- or numeric keys.
2. Press the start key. The value
is set.
Completion: Press the stop key.
If a preset value is raised, a picture will move to
the left.
To make an adjustment for duplex copying,
select [Dup].
(Original:test pattern)
2 Adjusting the center line of the cas-
settes
(printing adjustment)
Adjusting the LSU print start timing
U034 LSU Out Left P.1-3-24 1. Press the start key.
2. Select [Lsu Out Left] to be adjusted.
3. Press the start key.
4. Press the system menu key.
5. Press the start key.
(output a test pattern)
6. Press the system menu key.
7. Select the item to be adjusted.
[Cassette1] to [Cassette7]
1. Change the setting value using
the cursor +/- or numeric keys.
2. Press the start key. The value
is set.
Completion: Press the stop key.
If a preset value is raised, a picture will move to
the left.
To make an adjustment for duplex copying,
select [Dup].
(Original:test pattern)
3 Adjusting the leading edge registra-
tion of the MP tray
(printing adjustment)
secondary paper feed start timing
U034 LSU Out Top P.1-3-24 1. Press the start key.
2. Select [Lsu Out Top] to be adjusted.
3. Press the start key.
4. Press the system menu key.
5. Press the start key.
(output a test pattern)
6. Press the system menu key.
7. Select [MPT(L)] or [MPT(S)] to be
adjusted.
1. Change the setting value using
the cursor +/- or numeric keys.
2. Press the start key. The value
is set.
Completion: Press the stop key.
If a preset value is raised, a picture will move
downward.
To make an adjustment for duplex copying,
select [Dup].
(Original:test pattern)
4 Adjusting the leading edge registra-
tion of the cassette
(printing adjustment)
secondary paper feed start timing
U034 LSU Out Top P.1-3-24 1. Press the start key.
2. Select [Lsu Out Top] to be adjusted.
3. Press the start key.
4. Press the system menu key.
5. Press the start key.
(output a test pattern)
6. Press the system menu key.
7. Select [Cassette(L)] or [Caseette(S)] to
be adjusted.
1. Change the setting value using
the cursor +/- or numeric keys.
2. Press the start key. The value
is set.
Completion: Press the stop key.
If a preset value is raised, a picture will move
downward.
To make an adjustment for duplex copying,
select [Dup].
(Original:test pattern)
5 Adjusting the leading edge margin
(printing adjustment)
LSU illumination start timing
U402 Lead P.1-3-51 1. Press the start key.
2. Press the system menu key.
3. Press the start key.
(output a test pattern)
4. Press the system menu key.
5. Select [Lead] to be adjusted.
1. Change the setting value using
the cursor +/- or numeric keys.
2. Press the start key. The value
is set.
Completion: Press the stop key.
A margin will become large if a preset value is
raised.
(Original:test pattern)
6 Adjusting the trailing edge margin
(printing adjustment)
LSU illumination end timing
U402 Trail P.1-3-51 1. Press the start key.
2. Press the system menu key.
3. Press the start key.
(output a test pattern)
4. Press the system menu key.
5. Select [Trail] to be adjusted.
1. Change the setting value using
the cursor +/- or numeric keys.
2. Press the start key. The value
is set.
Completion: Press the stop key.
A margin will become large if a preset value is
raised.
(Original:test pattern)
