Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6-1
2-3-1
2-3 Appendixes
2-3-1 Appendixes
(1) List of maintenance parts
Maintenance part name
Part No.
Alternative
part No.
Name used in service manual Name used in parts list
Paper feed pulley
Pickup pulley
PULLEY FEED ASSY
PARTS PULLEY PICKUP ASSY SP
(PARTS HOLDER FEED ASSY SP)
302F906230
-
(302LV94270)
2F906230
-
(2LV94270)
Separation pulley RETARD ROLLER ASSY
(CT-3100)
302F909171
(302MS93011)
2F909171
(2MS93011)
Contact glass
Slit glass
CONTACT GLASS
CONTACT GLASS DP
(PARTS FRAME ISU TOP ASSY SP)
-
-
(302NM94030)
-
-
(2NM94030)
CCD
LED
P.W.BOARD ASSY CCD
P.W.BOARD ASSY LED
(PARTS ISU ASSY SP)
-
-
(302NM93010)
-
-
(2NM93010)
MP paper feed roller ROLLER M/P ASSY 302HS08260 2HS08260
MP separation pad PAD SEPARATION MPF - -
Upper ragistration roller PARTS ROLLER REGIST UP SP 302LV94180 2LV94180
Lower ragistration roller PARTS ROLLER REGIST LOW SP 302LV94170 2LV94170
Transfer roller PARTS ROLLER TRANSFER SP 302LV94130 2LV94130
Paper chute guide PARTS GUIDE PAPER CHUTE SP 302LV94261 2LV94261
DU conveying roller ROLLER DU ASSY - -
DU conveying pulley PULLEY PA - -
Upper eject roller ROLLER FD UP - -
Upper eject pulley PULLEY EXIT - -
Lower eject roller ROLLER FD UP - -
Lower eject pulley PULLEY EXIT FUSER - -
DP pickup pulley
DP paper feed roller
DP separation pad
PULLEY PICKUP ASSY
PULLEY PAPER FEED ASSY
PAD SEPARATION
(PARTS DP UNIT SP)
-
-
-
(302NZ94060)
-
-
-
(2NZ94060)

Kyocera ECOSYS M3540dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Type	Color CIS
Scan Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Paper Capacity	500 sheets
Connectivity	USB, Ethernet
Copying	Yes
Scanning	Yes
Modem Speed	33.6 kbps
Standard Input Capacity	500 sheets
Standard Output Capacity	250 sheets
Maximum Output Capacity	250 sheets
Maximum Print Size	A4
Standard Interfaces	USB 2.0, Ethernet
Ethernet LAN	Yes
Internal Memory	512 MB
Power Consumption (typical)	661 W
Display	LCD
Functions	Print, Copy, Scan, Fax
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm (pages per minute)
Copy Speed	40 cpm (copies per minute)
Standard Paper Tray Media Types	Recycled
Maximum Internal Memory	1, 536 MB
Weight	22 kg
Product Colour	Black
