Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-3-2
(2) Maintenance modes item list
Section
Item
No.
Content of maintenance item Summary
General U000 Mainte Report It outputs to printing of each report, and
USB.
U001 Exit Mainte Maintenance mode is canceled.
U002 Set Factory Def A factory-shipments setup (initialization)
and packing mode are set up.
U004 Machine No. The display of machine serial No. and
serial No. acquired from the engine at the
time of substrate exchange are copied to
MAIN backup.
U010 Set Mainte ID The brittleness of a security function is pre-
vented by changing ID.
U019 Firm Version Each soft version is displayed.
Initializa-
tion
U021 Init memory The backup data except an adjustment
value is initialized.
U025 Firm Update(S) Only an administrator can be made to do
FW-UPDATE.
Drive,
paper feed
and paper
conveying
system
U034 Adj Paper Timing The timing data of leading edge and the
center line adjustment data in a paper stan-
dard are set up.
Optical U065 Adj Scn The degrees of the main and auxiliary
scanning direction at the time of table read-
ing are adjusted.
U066 Table Timing The timing of leading edge and trailing
edge at the time of table reading are
adjusted.
U067 Table Center The position of main scanning direction at
the time of table reading are adjusted.
U068 DP Scn Start Pos The timing of starting position at the time of
DP reading are adjusted.
U070 Adj DP Motor The degree of auxiliary scanning direction
are adjusted by adjusting the speed of time
of DP reading.
U071 DP Timing The timing of DP reading are adjusted.
U072 DP Center The center line of DP reading image are
adjusted.
Developer U130 Set Toner Install Installation of a toner is performed.
U147 Set Toner Apply Same as the above

Kyocera ECOSYS M3540dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Type	Color CIS
Scan Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Paper Capacity	500 sheets
Connectivity	USB, Ethernet
Copying	Yes
Scanning	Yes
Modem Speed	33.6 kbps
Standard Input Capacity	500 sheets
Standard Output Capacity	250 sheets
Maximum Output Capacity	250 sheets
Maximum Print Size	A4
Standard Interfaces	USB 2.0, Ethernet
Ethernet LAN	Yes
Internal Memory	512 MB
Power Consumption (typical)	661 W
Display	LCD
Functions	Print, Copy, Scan, Fax
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm (pages per minute)
Copy Speed	40 cpm (copies per minute)
Standard Paper Tray Media Types	Recycled
Maximum Internal Memory	1, 536 MB
Weight	22 kg
Product Colour	Black
