Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-4-66
(13) Image is out of focus.
1. Table scanning
2. DP-scanning
Print example
Defective part Check description Corrective Action
1
Original document Check whether the original
document is wavy.
If the original document is wavy, straighten.Or,
replace the original document.
2
Contact glass Check whether the contact glass
is dew condensed.
If the contact glass is dew condensed, remove
the dew.
3
Mirror Check whether the mirror is dew
condensed.
If the mirrors are dew-condensed, remove the
dew.
4
Lens Check whether the lens is dew
condensed.
If the lens is dew condensed, remove the dew.
5
CCD sensor Check whether the CCD sensor
glass is dew condensed.
If the CCD sensor glass is dew condensed,
remove the dew.
6
Adjustment of the
scanner
Check the automatic adjustment
of the scanner.
Perform maintenance mode U411,
table(Chart1)_All.
(see page 1-3-54)
7
ISU Confirm the position of the lens
and the CCD sensor.
If the lenses and the CCD sensor are
misaligned, replace the ISU and perform U411.
(see page 1-3-54)
8
Control PWB The control PWB is defective. Replace the control PWB.(see page 2-2-12)
Defective part Check description Corrective Action
1
Original document Check whether the original
document is wavy.
If the original document is wavy, straighten.Or,
replace the original document.
2
Slit glass Check whether the slit glass is
dew condensed.
If the slit glass is dew condensed, remove the
dew.
3
Mirror Check whether the mirror is dew
condensed.
If the mirrors are dew-condensed, remove the
dew.
4
Lens Check whether the lens is dew
condensed.
If the lens is dew condensed, remove the dew.

Kyocera ECOSYS M3540dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Type	Color CIS
Scan Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Paper Capacity	500 sheets
Connectivity	USB, Ethernet
Copying	Yes
Scanning	Yes
Modem Speed	33.6 kbps
Standard Input Capacity	500 sheets
Standard Output Capacity	250 sheets
Maximum Output Capacity	250 sheets
Maximum Print Size	A4
Standard Interfaces	USB 2.0, Ethernet
Ethernet LAN	Yes
Internal Memory	512 MB
Power Consumption (typical)	661 W
Display	LCD
Functions	Print, Copy, Scan, Fax
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm (pages per minute)
Copy Speed	40 cpm (copies per minute)
Standard Paper Tray Media Types	Recycled
Maximum Internal Memory	1, 536 MB
Weight	22 kg
Product Colour	Black
