Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6-1
2-1-9
1. Main motor (MM) *1 .............................. Drives the paper feed section and conveying section.
2. Main motor (MM) *2 .............................. Drives the paper feed section and conveying section.
3. Drum motor (DRM) *2 ........................... Drives the drum unit and transfer roller.
4. Lift motor (LM)*2 ................................... Operates the bottom plate in the cassette.
5. Image scanner motor (ISUM)................ Drives the ISU.
6. Polygon motor (PM) .............................. Drives the polygon mirror.
7. Toner motor (TM) .................................. Replenishes toner to the developing unit.
8. Eject motor (EM) ................................... Drives the duplex section.
9. Envelope motor (ENVM) *2................... Drives the change mechanism of fixing pressure in fuser unit.
10. Developer fan motor (DEVFM) ............. Cools the developer section.
11. LSU fan motor (LSUFM) ....................... Cools the LSU unit.
12. Power source fan motor (PSFM) .......... Cools the power source PWB.
13. DP paper feed motor (DPPFM)............. Drives the original feed section.
14. DP paper conveying motor (DPCM) ..... Drives the original conveying section.
15. DP switchback motor (DPSBM) ............ Drives the switchback roller.
List of correspondences of motor names
No. Name used in service manual Name used in parts list Part.No.
1 Main motor (MM) *1 PARTS MOTOR-BL W30 SP 302K394201
2 Main motor (MM) *2 PARTS MOTOR-BL W30 SP 302K394201
3 Drum motor (DRM) *2 PARTS MOTOR-BL W30 SP 302K394201
4 Lift motor (LM) *2 PARTS DC MOTOR ASSY SP 302LV94230
5 Image scanner motor (ISUM) MOTOR ISU 302H994270
6 Polygon motor (PM)
MOTOR POLYGON
(LK-3200)
(LK-3230) *7
-
(302NZ93010)
(302P693010)
7 Toner motor (TM)
TONER MOTOR ASSY
(DK-3100(U)) *1
(DK-3100(E)) *1
(DK-3100(AO)) *1
(DK-3130(U)) *2
(DK-3130(E)) *2
(DK-3130(AO)) *2
-
(302MS93042)
(302MS93022)
(302MS93052)
(302LV93062)
(302LV93042)
(302LV93072)
8 Eject motor (EM) MOTOR EJECT 302F944131
9 Envelope motor (ENVM) PARTS DC MOTOR ASSY SP 302LV94230
10 Developer fan motor (DEVFM) FAN MOTOR 302HN44010
11 LSU fan motor (LSUFM) FAN LSU 60-25 302GR44080
12 Power source fan motor (PSFM) PARTS,FAN COOLING CONVEYING SP 302FZ94420
13 DP paper feed motor (DPPFM)
MOTOR PAPER FEED
(PARTS DRIVE ASSY A SP)
-
(302NM94230)
14 DP paper conveying motor (DPCM)
MOTOR-HB PAPER FEED
(PARTS DRIVE ASSY A SP)
-
(302NM94230)

Kyocera ECOSYS M3540dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Type	Color CIS
Scan Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Paper Capacity	500 sheets
Connectivity	USB, Ethernet
Copying	Yes
Scanning	Yes
Modem Speed	33.6 kbps
Standard Input Capacity	500 sheets
Standard Output Capacity	250 sheets
Maximum Output Capacity	250 sheets
Maximum Print Size	A4
Standard Interfaces	USB 2.0, Ethernet
Ethernet LAN	Yes
Internal Memory	512 MB
Power Consumption (typical)	661 W
Display	LCD
Functions	Print, Copy, Scan, Fax
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm (pages per minute)
Copy Speed	40 cpm (copies per minute)
Standard Paper Tray Media Types	Recycled
Maximum Internal Memory	1, 536 MB
Weight	22 kg
Product Colour	Black
