Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-3-21
U019 Firm Version
Description
Displays the part number of the ROM fitted to each board.
Purpose
To check the part number or to decide, if the newest version of ROM is installed.
Method
1. Press the start key. The ROM version are displayed.
2. Change the screen using the cursor up/down keys.
Display Description
Main Main ROM
MMI Operation ROM
Browser *1 Browser ROM
Engine Engine ROM
Engine Boot Engine booting
Dictionary *1 Dictionary ROM
Option Language Optional language ROM
Cass2 Cassette2 ROM
Cass2 Boot Cassette2 booting
Cass3 Cassette3 ROM
Cass3 Boot Cassette3 booting
Cass4 Cassette4ROM
Cass4 Boot Cassette4 booting
Cass5 Cassette5 ROM
Cass5 Boot Cassette5 booting
Fax APL *2 Fax APL
Fax Boot *2 Fax booting
Fax IPL *2 Fax IPL
Application Name1 *1 Application1 ROM
Application Name2 *1 Application2 ROM
Application Name3 *1 Application3 ROM
Application Name4 *1 Application4 ROM
Application Name5 *1 Application5 ROM
*1: HyPAS model only
*2: FAX model only
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.

Kyocera ECOSYS M3540dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Type	Color CIS
Scan Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Paper Capacity	500 sheets
Connectivity	USB, Ethernet
Copying	Yes
Scanning	Yes
Modem Speed	33.6 kbps
Standard Input Capacity	500 sheets
Standard Output Capacity	250 sheets
Maximum Output Capacity	250 sheets
Maximum Print Size	A4
Standard Interfaces	USB 2.0, Ethernet
Ethernet LAN	Yes
Internal Memory	512 MB
Power Consumption (typical)	661 W
Display	LCD
Functions	Print, Copy, Scan, Fax
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm (pages per minute)
Copy Speed	40 cpm (copies per minute)
Standard Paper Tray Media Types	Recycled
Maximum Internal Memory	1, 536 MB
Weight	22 kg
Product Colour	Black
