Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6-1
2-3-3
(3) Repetitive defects gauge
* : The repetitive marks interval may vary depending on operating conditions.
44.9 mm/1 3/4” Developer roller
36.8 mm/1
7/16” Registration roller
29.9 mm/1
3/16” Chager roller
94.2 mm/3
11/16” Drum/Press roller (50/60 ppm model)
109.9 mm/4
5/16” Heat roller (50/60 ppm model)
78.5 mm/3 1/16” Press roller (40 ppm model)
84.8 mm/3 5/16” Heat roller (40 ppm model)
61.2 mm/2 7/16” Transfer roller
First occurrence of defect
