Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6-1
1-3-40
U207 Chk Panel Key
Description
Checks operation of the operation panel keys.
Purpose
To check operation of all the keys on the operation panel.
Method
1. Press the start key. The screen for executing is displayed.
2. [Count0] is displayed and the left most LED on the operation panel lights.
Display Description
Cnt Keypress counter.
3. As the keys lined up in the same line as the lit indicator are pressed in the order from the top to
the bottom, the figure shown on the touch panel increases in increments of 1. When all the
keys in that line are pressed and if there are any LEDs corresponding to the keys in the line on
the immediate right, the top LED in that line will light.
4. When all the keys on the operation panel have been pressed, all the LEDs light for up to 10
seconds.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.

Kyocera ECOSYS M3540dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Type	Color CIS
Scan Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Paper Capacity	500 sheets
Connectivity	USB, Ethernet
Copying	Yes
Scanning	Yes
Modem Speed	33.6 kbps
Standard Input Capacity	500 sheets
Standard Output Capacity	250 sheets
Maximum Output Capacity	250 sheets
Maximum Print Size	A4
Standard Interfaces	USB 2.0, Ethernet
Ethernet LAN	Yes
Internal Memory	512 MB
Power Consumption (typical)	661 W
Display	LCD
Functions	Print, Copy, Scan, Fax
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm (pages per minute)
Copy Speed	40 cpm (copies per minute)
Standard Paper Tray Media Types	Recycled
Maximum Internal Memory	1, 536 MB
Weight	22 kg
Product Colour	Black
