Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-3-108
FAX call Setting FAX call setting
Description
Selects if a fax is to be connected to either a PBX or public switched telephone network.
Selects the mode to connect an outside call when connected to a PBX.
Access code registration for connection to PSTN.
Purpose
To be executed as required.
Method
1. Enter the Service Setting menu.
2. Select [FAX Call Set.].
3. Press the start key.
Setting the connection to PBX/PSTN
1. Select [Exchange Select.].
2. Press the start key.
3. Select [PBX] or [PSTN].
4. Press the start key. The setting is set.
Setting for PBX
1. Select [PBX Setting].
2. Press the start key.
3. Select [Loop], [Flash] or [Earth].
4. Press the start key. The setting is set.
Setting access code to PSTN
1. Select [Dial No. to PSTN].
2. Press the start key.
3. Enter access code using the numeric keys. (0 to 9, 00 to 99)
4. Press the start key. The setting is set.
Completion
Press the stop key.
Service items Description
Display Description
Exchange Select. Setting the connection to PBX/PSTN
PBX Setting Setting for a PBX
Dial No. to PSTN Setting access code to PSTN

Kyocera ECOSYS M3540dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Type	Color CIS
Scan Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Paper Capacity	500 sheets
Connectivity	USB, Ethernet
Copying	Yes
Scanning	Yes
Modem Speed	33.6 kbps
Standard Input Capacity	500 sheets
Standard Output Capacity	250 sheets
Maximum Output Capacity	250 sheets
Maximum Print Size	A4
Standard Interfaces	USB 2.0, Ethernet
Ethernet LAN	Yes
Internal Memory	512 MB
Power Consumption (typical)	661 W
Display	LCD
Functions	Print, Copy, Scan, Fax
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm (pages per minute)
Copy Speed	40 cpm (copies per minute)
Standard Paper Tray Media Types	Recycled
Maximum Internal Memory	1, 536 MB
Weight	22 kg
Product Colour	Black
