Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-4-12
(2) Items and corrective actions relating to the device that will cause paper jam
Jam types Check description Corrective measures
No-paper-feed jam or
the leading edge of
paper is curled back at
the position of the
roller
(J0501, J0502, J0503,
J0504, J0505, J0509)
1. Check if the jammed
paper or the printed
paper has a tear
caused by the roller at
its leading edge.
Replace the paper feed roller.(Service life of rubber
roller is 300000 images *1)
Increase the spring pressure to pinch the separation
rollers if the component is undue to its expected
life.Replace the spring.
2. Check abrasion and
paper dusts on the feed
roller and forward
rollers.
Clean the paper feed roller and the pickup roller. Or, if
not amended, replace.
3. Check the pickup roller
and paper feed roller
are rotating.
If disconnected or or stained, replace the primary
paper feed clutch.
4. Check that the
conveying force of the
pickup roller is
sufficient.
Increase the conveying force during paper pickup by
increasing the spring load of the pickup roller.
*1: 40 ppm model (Service life of 50/60 ppm model is 500000 images.)

Kyocera ECOSYS M3540dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Type	Color CIS
Scan Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Paper Capacity	500 sheets
Connectivity	USB, Ethernet
Copying	Yes
Scanning	Yes
Modem Speed	33.6 kbps
Standard Input Capacity	500 sheets
Standard Output Capacity	250 sheets
Maximum Output Capacity	250 sheets
Maximum Print Size	A4
Standard Interfaces	USB 2.0, Ethernet
Ethernet LAN	Yes
Internal Memory	512 MB
Power Consumption (typical)	661 W
Display	LCD
Functions	Print, Copy, Scan, Fax
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm (pages per minute)
Copy Speed	40 cpm (copies per minute)
Standard Paper Tray Media Types	Recycled
Maximum Internal Memory	1, 536 MB
Weight	22 kg
Product Colour	Black
