Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6-1
1-2-3
Figure 1-2-2
*: Place the machine on a level surface.
Unpacking
11
13
12
1
1
1
1
16
18
10
14
7
8
5
4
2
6
9
15
3
17
1. Hinge joints
2. Outer case
3. Upper front pad
4. Upper left pad
5. Upper right pad
6. Waste toner box
7. Power code
8. Operation guide etc.
9. Plastic bag
10. Document tray
11. Main unit
12. Inner pad
13. Plastic bag
14. Plastic bag
15. Lower left pad
16. Lower right pad
17. Lower front pad
18. Bottom case

Kyocera ECOSYS M3540dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Type	Color CIS
Scan Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Paper Capacity	500 sheets
Connectivity	USB, Ethernet
Copying	Yes
Scanning	Yes
Modem Speed	33.6 kbps
Standard Input Capacity	500 sheets
Standard Output Capacity	250 sheets
Maximum Output Capacity	250 sheets
Maximum Print Size	A4
Standard Interfaces	USB 2.0, Ethernet
Ethernet LAN	Yes
Internal Memory	512 MB
Power Consumption (typical)	661 W
Display	LCD
Functions	Print, Copy, Scan, Fax
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm (pages per minute)
Copy Speed	40 cpm (copies per minute)
Standard Paper Tray Media Types	Recycled
Maximum Internal Memory	1, 536 MB
Weight	22 kg
Product Colour	Black
