Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6-1
2-1-7
*1: 40 ppm model only
*2: 50/60 ppm model only
10
Fuser thermistor2 (FTH2)
THERMISTOR ASSY
(FK-3100(U)) *1
(FK-3100(E)) *1
(FK-3130(U)) *2
(FK-3130(E)) *2
-
(302MS93094)
(302MS93074)
(302LV93132)
(302LV93112)
11 Power source switch (PSSW) PARTS PWB ASSY SWITCH SP 302LV94210
12 Inter lock switch (ILSW) INTER LOCK SWITCH 2FB27160
13 Rear cover switch (RCSW) *2 SW.PUSH 7SP01000006+H01
14 Paper full sensor (PFS) SENSOR OPT. 303M894260
15 Envelope sensor (ENVS) SENSOR OPT. 303M894260
16 Cassette size switch (CSSW) SW.PUSH -
17 DP original sensor (DPOS) SENSOR OPT. -
18
DP registration sensor (DPRS)
SENSOR OPT.
(PARTS DRIVE ASSY A SP)
-
(302NM94230)
19
DP timing sensor (DPTS)
SENSOR OPT.
(PARTS DRIVE ASSY A SP)
-
(302NM94230)
20 DP switchback sensor (DPSBS)
SENSOR OPT. -
21
DP open/close sensor (DPOCS)
SENSOR OPT.
(PARTS DRIVE ASSY A SP)
-
(302NM94230)
No. Name used in service manual Name used in parts list Part.No.
